Then we try to receive it into the new project. This is a total of 3 elements and send them all individually to speckle. We take all the individual components from the main Generic model adaptive (GMA). We have placed it in the project and still it was unable to find it. Wich is strange because we have it loaded into the project. Speckle again did not find the needed type of the family. Lets test it again but this time we pre load the main family of the wanted items, this is one of the GMA’s inside the main GMA family. The element were again replaced with another type but speckle did place the elements in the model, which is an upgrade from our previous test. It seems that there is a change in behavior. Now we take this Family and try to use Speckle on it an receive it in a clean template file. Interestingly the type that replaced the family is also a Generic model adaptive (GMA). The family type that is selected is one of the GMA inside the main GMA, which is odd. Speckle was unable to load the needed types and replaced them with a family type of another object. We delete the objects that have been send to Speckle.Īfter trying to receive them again from Speckle we get the same issue. If this is succesvol we can conclude that this is the problem. Now we want to check if its possible to load the wanted elements in the original File that has the families and their types already loaded. When we preload a home made GMA it works(right image). Lets see if it helps to pre load the family. It appears that Speckle requires Revit to have the family and its types already loaded to be able to create them. It replace the type with a already loaded family type that was in the used template(left image). It might have trouble gathering the information of the GMA Lets try and see what it does to another GMA(this one has 3 GMA in it as well).Īgain Speckle could not load the wanted family type. It looks like Speckle is replacing the wanted family type with antoher type that is unrelevant to the main family that was used originally.
When I try to “reveive” them into my other project they fail to find the needed type and do not get loaded into the file.
The GMA consist of 3 GMA’s inside it, these have shared checked on. I want to send these files toward Speckle and use them in another project. I have a couple of different Generic model adaptive (I will refer to them as GMA).
